| Model | 50A | LS 60A |
| Maximum charge current | 50A | 60A |
| Maximum discharge current | 50A | 60A |
| System voltage | 12/24V | |
| The battery type | Lead acid battery | |
| Solar panel maximum input voltage | 50V | |
| Floating voltage | 13. 8V(13-15V),27.6V(26-30V).55.2V(52-60V) | |
| Increase the charge | 14.4V/28.8V/57.6V The battery voltage is below 12V/24V/48V | |
| Battery overpressure | 15V/30V/60V | |
| Protection Input reverse | YES | |
| Self loss | ≦13 MA | |
| connection protection Load over current | Yes, every two seconds to restart | |
| Temperature compensation | -24mv/°C,-48mv/°C,, Relative to 12V/24V system. | |
| Operating temperature | -20～ 55℃ | |
| Waterproof level | IP32 | |
| Product Size(mm)/Weight(g) | 187*122*57mm / 680g | |
| Packing size(mm) | 500*500*450mm | |
| Packing quantity(pcs) | 50 | |
